MPO/MTP Data Center Cabling
SN-MT Assembly
The SN-MT connector is a popular fiber optic connector used across data centers, telecommunications, and optical networking.
Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.
100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof
Description
The SN-MT connector is a popular fiber optic connector used across data centers, telecommunications, and optical networking. Known for its compact size and high performance, it offers a reliable solution for connecting optical fibers in a variety of applications. As demand grows for faster data transmission and improved connectivity, the SN-MT connector has become an essential component in modern optical networks.
Technical Specifications
Performance Characteristics
| Item | Single-mode | Multimode | Reference |
|---|---|---|---|
| Insertion loss (SN-MT) | ≤0.35 dB | ≤0.35 dB | IEC 61300-3-3, IEC 61300-3-6 |
| Return loss (SN-MT) | ≥60 dB (APC) | ≥35 dB (APC) | |
| Insertion loss (SN) | ≤0.35 dB | ≤0.35 dB | |
| Return loss (SN) | ≥50 dB (UPC); ≥60 dB (APC) | ≥30 dB (PC) | |
| Insertion loss (MPO) | ≤0.35 dB | ≤0.35 dB | |
| Return loss (MPO) | ≥60 dB (APC) | ≥30 dB (PC); ≥35 dB (APC) | |
| Insertion loss (Uniboot LC) | ≤0.35 dB | ≤0.35 dB | |
| Return loss (Uniboot LC) | ≥50 dB (UPC); ≥60 dB (APC) | ≥30 dB (PC) | |
| Operating temperature | -10 ℃ ~ +60 ℃ | ||
| Storage temperature | -20 ℃ ~ +70 ℃ |
Cable Characteristics
| Item | Value |
|---|---|
| Fiber number | 16 |
| Fiber type | SM, MM |
| Strength member | Aramid yarn |
| Outer jacket | LSZH, OFNR, OFNP or customized |
| Outer diameter | 2.0 ± 0.1 mm / 2.6 ± 0.1 mm |
| Min bending radius (dynamic / static) | 20D / 10D |
| Max allowable tensile (short / long term) | 100 N / 30 N |
Optical Fiber Characteristics
| Fiber type | Attenuation 1310/1550nm typ (dB/km) | Attenuation 850/1300nm typ (dB/km) | Effective modal bandwidth 850nm (MHz·km) | Min bend radius (mm) |
|---|---|---|---|---|
| G.657A1 | 0.36 / 0.22 | — | — | 10 |
| G.657A2 | 0.36 / 0.22 | — | — | 7.5 |
| OM1 | — | 3.0 / 1.0 | — | 30 |
| OM2 | — | 3.0 / 1.0 | — | 30 |
| OM3 | — | 3.0 / 1.0 | ≥2000 | 30 |
| OM4 | — | 3.0 / 1.0 | ≥4700 | 30 |
| OM5 | — | 3.0 / 1.0 | ≥4700 | 30 |
Features
- High-density design: supports a high-density configuration, packing more fibers into a smaller space
- Fast installation: designed for quick, easy installation that reduces setup time and labor
- Low insertion loss: engineered to minimize insertion loss for efficient transmission with minimal signal degradation
- Durability: made from durable materials for long-lasting performance even in harsh environments
Applications
- Data centers
- Telecommunications
- Optical networking
