FTTA Cabling Series
FULLX (LC) Outdoor Waterproof Connector
The FULLX (LC) outdoor cable assembly delivers IP68 protection with low insertion and return loss for steady optical transmission.
Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.
100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof
Description
The FULLX (LC) outdoor cable assembly delivers IP68 protection with low insertion and return loss for steady optical transmission. Its lightweight metal hard housing and open-bulkhead design provide easy access to the SFP, making it suited to Fiber-to-the-Antenna (FTTA), base-station, and harsh outdoor environments.
Technical Specifications
Optical & Performance Parameters
| Item | SM-UPC (Typical / MAX) | SM-APC (Typical / MAX) | MM-UPC (Typical / MAX) |
|---|---|---|---|
| Insertion loss | ≤0.15 / ≤0.3 dB | ≤0.15 / ≤0.3 dB | ≤0.15 / ≤0.3 dB |
| Return loss | Min. 50 dB | Min. 60 dB | Min. 30 dB |
| Item | Single mode | Multi mode |
|---|---|---|
| Operating wavelength | 1310 nm ~ 1550 nm | 850 nm ~ 1300 nm |
| Test wavelength | 1310 nm & 1550 nm | 850 nm & 1300 nm |
| Item | Parameter |
|---|---|
| Durability | 200 cycles |
| Operating temperature | -20 to +70 °C |
| Storage temperature | -40 to +85 °C |
| Installation temperature | -20 to +70 °C |
| Waterproofing grade | IP68 (1 m, 1 hour) |
| Cable diameter range | 4.8 mm ~ 7.0 mm |
| Standards | Comply to GR-1320, IEC 61753-1, IEC 61754-4 |
Assembly
| Item | SM-UPC | SM-APC | MM-UPC |
|---|---|---|---|
| Insertion loss | Max. 0.3 dB + 0.35 dB/km × L | Max. 0.3 dB + 0.35 dB/km × L | Max. 0.3 dB + 3.0 dB/km × L |
| Return loss | Min. 50 dB | Min. 60 dB | Min. 30 dB |
Features
- IP68 protection, humidity proof, dust proof
- Low insertion / return loss, steady optical transmitting
- Light weight and metal hard housing
- Open bulkhead for easy access to SFP
Applications
- Fiber-to-the-Antenna (FTTA)
- WiMAX and LTE base stations
- Remote Radio Heads (RRH)
- Industrial outdoor applications
- CATV, LAN & WAN
- Aerospace & defense
