Outdoor Fiber Optic Cable
GYDXTW Outdoor Cable
GYDXTW is an Aerial or Duct use fiber optic cable. We supply GYDXTW cable from 2 cores to 144 cores with both single mode and multi mode types.
Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.
100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof
Description
GYDXTW is an Aerial or Duct use fiber optic cable. We supply GYDXTW cable from 2 cores to 144 cores with both single mode and multi mode types.
Technical Specifications
Cable type | OD(mm) | Nominal Weight (Kg/Km) | Tensile Strength(N) | Crush Resistance (N/100MM) | Bending Radius(mm) |
|---|
|
|
| Short-term | Long-term | Short-term | Long-term | Dynamic | Static |
GYDXTW-12~48Xn | 11.8±0.5 | 164.0 | 2000 | 600 | 1000 | 300 | 20D | 15D |
GYDXTW-60~72Xn | 13.0±0.5 | 181.0 | 2000 | 600 | 1000 | 300 | 20D | 15D |
GYDXTW-74~96Xn | 13.5±0.5 | 194.0 | 2000 | 600 | 1000 | 300 | 20D | 15D |
GYDXTW-98~120Xn | 14.5±0.5 | 212.0 | 2000 | 600 | 1000 | 300 | 20D | 15D |
GYDXTW-122~144Xn | 15.0±0.5 | 228.0 | 2000 | 600 | 1000 | 300 | 20D | 15D |
Storage/Working temperature(℃) | -40~+70 |
|
|
|
|
Notes:
- Note: Xn is fiber optic model and D is the diameter of optical cable.
Features
- Low dispersion and attenuation.
- Small cable diameter, Light cable weight.
- Easily to lay, Large fiber count.
- Ribbon connection.
- Excellent mechanical and environmental properties.
- Moisture resistance and crush resistance.
Applications
- Access network.
- Aerial and duct application.
- Long-distance communication.
Packing
- Standard wooden drum with protection.
- Standard reel length: 2/3 km/reel, other length is also available.
