Indoor Fiber Optic Cable
GJSJBV Duplex Armoured Flat Cable
GJSJBV Duplex Armoured Flat Cable use 600um & 900um tight buffer fiber, steel tube protect, reinforcing steel-wire braiding (Kevlar/aramid yarn), flame-retardant jacket.
Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.
100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof
Description
GJSJBV Duplex Armoured Flat Cable use 600um & 900um tight buffer fiber, steel tube protect, reinforcing steel-wire braiding (Kevlar/aramid yarn), flame-retardant jacket. High indentation strength, high tensile strength, gopher protected, small diameter, flexibility and easy bend.
Technical Specifications
| Cable type | OD(mm) | Nominal Weight (Kg/Km) | Tensile Strength(N) | Crush Resistance (N/100MM) | Bending Radius(mm) |
|---|---|---|---|---|---|
| Short-term | Long-term | Short-term | |||
| GJSJBV-2Xn | (3.0±0.2)* (5.4±0.2) | 35.5 | 1000 | 300 | 2000 |
| GJSJBV-2Xn | (3.8±0.2)* (7.0±0.2) | 38.5 | 1000 | 300 | 2000 |
| Storage/Working temperature(℃) | -20~+60 |
Notes:
- Note: Xn is fiber optic model and D is the diameter of optical cable.
Features
- Two single-fiber as basic unit, flast twin configuration.
- Single –cable with 0.6mm or 0.9mm tight buffer .
- Kevlar yarn steel armored flexible or out sheath independent strength member.
- Excellent mechanical and enviromental performance .
Applications
- Adopted to indoor distribution.
- As pigtail of communication equipment .
- Suitable for communication equipment served .
- Can be installed conveniently and perated simply .
Packing
- Standard wooden drum with protection.
- Standard reel length: 2/3 km/reel, other length is also available.
