Indoor Fiber Optic Cable

3.0mm SM Armored Optical Cable

Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.

100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof

Description

Characteristic： The armored fiber optic cable which “can be freely used like electrical wire”,this item is protected by flexible stainless steel tube.Compare with the regular fiber cable,it have advantage performance of High compression & impact resistance,anti-bug. With fixed standard 3mm fiber optic connector,it widely used in various terrible environment. Geometrical Characteristics：

Technical Specifications

Item	Singlemode	Multimode
Outer diameter	3.0mm	3.0mm
Standard color	blue	gray
Cable weight	15kg/km approx
Operating temperature	PVC, OFNP -20℃~~+70℃; LSZH, TPU, PE -40℃~~+80℃
Storage temperature	-40℃~+80℃
Tensile strength - Short term	150N
Tensile strength - Long term	300N
Compression resistant strength	≥3000N/100MM
General attenuation - 1310nm	≤0.4dB/km	850nm ≤3.0dB/km
General attenuation - 1550nm	≤0.3dB/km	1300nm ≤1.0dB/km
Minimal Bending radius	≥30D	≥30D
Printing contents	OPTICAL CABLE SM(G652) 3.0mm SIMPLEX XXXXM	OPTICAL CABLE MM(62.5/125) 3.0mm SIMPLEX XXXXM
