Indoor Fiber Optic Cable
GJPFJV Distribution Cable
Multi-fiber GJPFJV tight-buffered indoor distribution cable for equipment rooms, ODF connections, tray or conduit routes and data-center internal cabling, available from 4F to 12F.
Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.
100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof
Description
GJPFJV is a multi-fiber tight-buffered distribution cable for organized indoor routing between equipment, optical distribution frames and termination points. Its non-unitized round construction combines individually identifiable fibers with a flexible outer jacket for stripping, splicing and connectorization.
Confirmed 4F–12F Availability
Item | Available scope |
|---|---|
Fiber count | 4F, 6F, 8F and 12F documented constructions |
Single-mode fiber | G.652D, G.657A1, G.657A2, G.657B3 |
Multimode fiber | OM1, OM2, OM3, OM4, OM5 |
Jacket options | PVC, LSZH, OFNR, OFNP |
Documented cable OD | 4.8±0.2 mm to 6.8±0.2 mm by fiber count |
Working / storage temperature | -20 to +60 °C |
The existing dimensional table remains the controlled series reference. Jacket material and flame rating are confirmed for the selected construction rather than assumed across every fiber count.
Technical Specifications
Cable type | OD(mm) | Nominal Weight (Kg/Km) | Tensile Strength(N) | Crush Resistance (N/100MM) | Bending Radius(mm) |
|---|
|
|
| Short-term | Long-term | Short-term | Long-term | Dynamic | Static |
GJPFJV-4Xn | 4.8±0.2 | 16.2 | 660 | 200 | 1000 | 300 | 20D | 15D |
GJPFJV-6Xn | 5.2±0.2 | 20.0 | 660 | 200 | 1000 | 300 | 20D | 15D |
GJPFJV-8Xn | 6.2±0.2 | 26.0 | 660 | 200 | 1000 | 300 | 20D | 15D |
GJPFJV-12Xn | 6.8±0.2 | 31.5 | 660 | 200 | 1000 | 300 | 20D | 15D |
Storage/Working temperature(℃) | -20~+60 |
|
|
|
|
Notes:
- Note: Xn is fiber optic model and D is the diameter of optical cable.
Features
• Tight-buffered multi-fiber construction for direct indoor termination
• Documented 4F, 6F, 8F and 12F configurations
• Flexible round cable for routing, stripping, splicing and connectorization
• Color-coded fibers support identification during installation
• Single-mode and multimode fiber plus project-specific jacket options
Applications
• Equipment-room and optical distribution frame connections
• Tray and conduit runs inside buildings
• Structured horizontal and riser cabling
• Data-center internal fiber distribution
• Multi-fiber patch-cord and pigtail assemblies
Packing
- Standard wooden drum with protection.
- Standard reel length:2/3 km/reel,other length is also available.
