Indoor Fiber Optic Cable
GJFJV Duplex 8 - Type Cable
GJFJV Duplex 8 - Type Cable use 900um or 600um tight buffer fiber as optical communication medium, the tight buffer fiber wrapped with a layer of yarn as strength member, and the cable is completed with a figure 8…
Full specifications, samples and bulk pricing on request — we typically reply within 24 hours.
100% Pre-Shipment Tested
Insertion & return loss (IL/RL) verified on every assembly
17-Year Manufacturer
Three in-house factories with 100+ production lines
Vertically Integrated
Cable extrusion, molds and assembly under one roof
Description
GJFJV Duplex 8 - Type Cable use 900um or 600um tight buffer fiber as optical communication medium, the tight buffer fiber wrapped with a layer of yarn as strength member, and the cable is completed with a figure 8 outside jacket (PVC, OFNR, OFNP, LSZH or other material as requirements).
Technical Specifications
Cable type | OD(mm) | Nominal Weight (Kg/Km) | Tensile Strength(N) | Crush Resistance (N/100MM) | Bending Radius(mm) |
|---|
|
|
| Short-term | Long-term | Short-term | Long-term | Dynamic | Static |
GJFJV-2Xn | (1.8±0.2)* (3.7±0.2) | 8.2 | 200 | 100 | 500 | 100 | 20D | 15D |
GJFJV-2Xn | (2.8±0.2)* (5.8±0.2) | 11.6 | 200 | 100 | 500 | 100 | 20D | 15D |
Storage/Working temperature(℃) | -20~+60 |
|
|
|
|
Notes:
- Note: Xn is fiber optic model and D is the diameter of optical cable.
Features
- High strength Kevlar yarn member.
- High quality tight buffered or loose tube .
- Figure 8 structure, soft and easy to strip.
- Excellent temperature performance.
Applications
- Suitable for patch cord and pigtails ,indoor distribution .
- Suitable for various of communication equipments.
- Can be installed conveniently and operated simply.
Packing
- Standard wooden drum with protection.
- Standard reel length: 2/3 km/reel, other length is also available.
Related products
3.0mm SM Armored Optical Cable
Characteristic： The armored fiber optic cable which “can be freely used like electrical wire”,this item is protected by flexible stainless steel…
View details
GJBFJV Break out Cable
